Wide Span Nylon Plastic Butterfly Wall Anchors Large Wing For Aerated Concrete Lightweight Cavity Block

Name: Wide Span Nylon Plastic Butterfly Wall Anchors Large Wing For Aerated Concrete Lightweight Cavity Block
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Butterfly Anchor
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Butterfly Anchor
MOQ:	1000 Pieces
Price:	USD 0.03 - 0.10 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	5000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Product Name:

Wide Span Nylon Butterfly Toggle Anchor

Material:

Single-Piece Nylon PA6 Body With Integrated Wide Toggle Wings

Anchor Type:

Wide Span Butterfly Toggle Anchor

Diameter:

M6, M8

Length:

40 Mm - 70 Mm

Suitable Substrate:

Aerated Concrete Block, Lightweight Aggregate Block

Load Capacity:

Medium Duty - Up To 12 Kg In AAC Substrate

Head Type:

Pan Head With Phillips Drive

Application:

AAC Blocks, Lightweight Cavity Walls

Working Principle:

Wide Wings Fold To Insert Through Hole, Spring Open, Distribute Load

Packaging Details:

Export carton

Highlight:

nylon plastic butterfly wall anchors

plastic butterfly wall anchors large wing

nylon butterfly plastic toggle anchors

Product Description

Wide Span Nylon Butterfly Anchor Large Wing Hollow Wall Toggle Fastener for Aerated Concrete Lightweight Cavity Block

Product Description

The Wide Span Nylon Butterfly Anchor is specifically designed for aerated concrete block, lightweight cavity wall, and other porous hollow building materials where standard toggle wings have insufficient surface contact area. The anchor features oversized toggle wings with an expanded span that distributes holding force across a larger area of the porous cavity wall backing surface, preventing the toggle from pulling through or crushing the friable substrate material. The nylon PA6 toggle body with integrated wide-span wings is manufactured as a single injection-molded component, eliminating metal-to-plastic joint failure points.

Features

Oversized Wide-Span Toggle Wings: Expanded wing surface area distributes holding force across larger backing surface to prevent pull-through in porous and friable cavity wall substrates.

Single-Piece PA6 Construction: Toggle body with integrated wide-span wings eliminates metal-to-plastic joint failure points for enhanced reliability in soft substrate materials.

AAC and Lightweight Block Optimized: Specifically engineered for aerated autoclaved concrete blocks and lightweight aggregate blocks with lower compressive strength than standard masonry.

Substrate-Protective Load Distribution: Wide wing geometry minimizes localized stress on friable cavity wall substrate to prevent crushing or cracking during anchor deployment and loading.

Technical Parameters

General Information
Product Name	Wide Span Plastic Butterfly Anchor / Large Wing Toggle for AAC Blocks
Material	Single-Piece Nylon PA6 Body with Integrated Wide Expandable Wings + Matching Steel Screw
Color Options	Grey, Natural
Mechanism Type	Wide-span screw-tighten expansion: integrated single-piece PA6 wings distribute load across friable substrates
Dimensions & Compatibility
Anchor Diameter (Wings Closed)	10 mm – 12 mm
Anchor Length	40 mm – 70 mm
Thread Size Compatibility	M6, M8
Installation Hole Diameter	10 mm – 12 mm
Recommended Wall Thickness	15 mm – 30 mm (AAC/lightweight block)
Installation
Installation Method	Drill hole carefully (low percussion) → clean dust thoroughly → fold wide wings → insert → tighten screw gradually to expand
Installation Tool	Electric drill (low torque) + Screwdriver
Key Feature	Single-piece PA6 construction eliminates joint failure points; wide wings prevent substrate crushing in friable materials
Reusability	Not recommended; wing deformation possible in friable substrates
Performance & Load Capacity
Typical Load Capacity	8 – 12 kg per anchor in AAC substrate (reduced from standard due to substrate strength)
Heavy-Duty Compatibility	Not applicable (limited by substrate, not anchor strength)
Temperature Range	-25°C to +85°C
Environmental Compliance	RoHS Compliant, REACH Compliant
Standards Compliance	ISO 9001:2015
Application
Applicable Substrates	Aerated Autoclaved Concrete (AAC) blocks, Lightweight aggregate blocks, Thermal insulation blocks, Porous hollow blocks
Common Applications	Lightweight block wall fixtures, thermal block shelving, AAC block accessory mounting, soft substrate anchoring
Usage Restriction	Not for high-load applications; substrate compressive strength limits anchor capacity; avoid percussion drilling
Packaging & Compliance
Standard Packaging	Anchor + matching screw, packed in sets
Packaging Quantity	100 sets per box, export carton
Certifications	ISO 9001:2015 (manufacturing)

Wide Span Nylon Plastic Butterfly Wall Anchors Large Wing For Aerated Concrete Lightweight Cavity Block

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
