Pre Assembled Ceiling Hollow Wall Plastic Butterfly Anchor For Light Fixture Smoke Detector Mounting

Name: Pre Assembled Ceiling Hollow Wall Plastic Butterfly Anchor For Light Fixture Smoke Detector Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Butterfly Anchor
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Butterfly Anchor
MOQ:	1000 Pieces
Price:	USD 0.03 - 0.10 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	5000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Product Name:

Pre-Assembled Butterfly Toggle Anchor Ceiling Kit

Material:

Nylon PA6 Body + Zinc-Plated Steel Toggle Wings

Anchor Type:

Pre-Assembled Butterfly Toggle Anchor

Diameter:

M5, M6

Length:

40 Mm - 65 Mm

Suitable Substrate:

Ceiling Plasterboard 10-15 Mm

Load Capacity:

Medium Duty - Up To 12 Kg

Head Type:

Pan Head With Phillips Drive

Application:

Ceiling Lights, Smoke Detectors, Ceiling Fans

Working Principle:

Pre-assembled Screw, Fold Wings, Push Through Ceiling Hole, Tighten

Packaging Details:

Export carton

Highlight:

hollow wall plastic butterfly anchor

pre assembled butterfly anchor plastic

pre assembled plastic butterfly anchor

Product Description

Pre Assembled Butterfly Toggle Anchor Ceiling Hollow Wall Fastener Set for Light Fixture Smoke Detector Mounting

Product Description

The Pre-Assembled Butterfly Toggle Anchor Ceiling Kit is a ready-to-use hollow wall fastening set designed specifically for overhead installation including ceiling light fixtures, smoke detectors, ceiling fans, and suspended ceiling components. Each anchor comes pre-assembled with the screw partially inserted into the toggle body, allowing the installer to fold the wings, push through the ceiling hole, and tighten without separately handling the toggle and screw during overhead work. The pre-assembled design significantly reduces installation time and improves safety for ceiling applications.

Features

Pre-Assembled Overhead Design: Screw pre-inserted into toggle body eliminates separate handling of toggle and screw during ceiling installation for improved safety and speed.

Ceiling-Optimized Spring Tension: Wing spring tension calibrated for ceiling applications where gravity assists wing deployment behind the ceiling panel.

Ready-to-Use Complete Kit: Each anchor comes as a complete unit with pre-assembled screw, toggle body, and wing mechanism for immediate ceiling installation.

Clean Pan Head Finish: Pan head screws provide a neat finished appearance for visible ceiling fixture installations in residential and commercial settings.

Technical Parameters

General Information
Product Name	Pre-Assembled Plastic Butterfly Anchor Ceiling Kit
Material	Nylon PA6 Body & Expandable Wings + Matching Zinc-Plated Steel Screw (pre-assembled)
Color Options	White, Natural
Mechanism Type	Screw-tighten expansion: screw pre-inserted for one-handed overhead installation
Dimensions & Compatibility
Anchor Diameter (Wings Closed)	8 mm – 10 mm
Anchor Length	35 mm – 50 mm
Thread Size Compatibility	M5, M6
Installation Hole Diameter	8 mm – 10 mm
Recommended Wall Thickness	10 mm – 15 mm (ceiling plasterboard)
Installation
Installation Method	Drill ceiling hole → clean dust → fold wings → push through hole → tighten screw one-handed
Installation Tool	Electric drill + Screwdriver (Phillips PH2)
Key Feature	Pre-assembled screw eliminates separate handling of anchor and screw during overhead work
Reusability	Not recommended; anchor wing memory may be compromised after ceiling removal
Performance & Load Capacity
Typical Load Capacity	8 – 12 kg per anchor in 12.5 mm ceiling board (pull-out)
Heavy-Duty Compatibility	Not applicable (ceiling application limited by pull-out direction)
Temperature Range	-20°C to +70°C
Environmental Compliance	RoHS Compliant
Standards Compliance	ISO 9001:2015
Application
Applicable Substrates	Ceiling plasterboard, gypsum board, suspended ceiling panels
Common Applications	Ceiling light fixtures, smoke detectors, ceiling fans (lightweight), suspended ceiling components
Usage Restriction	Not for heavy ceiling fixtures exceeding 12 kg; not for plaster/lath ceilings
Packaging & Compliance
Standard Packaging	Pre-assembled anchor + screw unit, packed in sets
Packaging Quantity	100 sets per box, export carton
Certifications	ISO 9001:2015 (manufacturing)

Pre Assembled Ceiling Hollow Wall Plastic Butterfly Anchor For Light Fixture Smoke Detector Mounting

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
