TV Wall Mount Hollow Plastic Toggle Wall Anchors Pre Assembled M8x70mm Screw Size

Name: TV Wall Mount Hollow Plastic Toggle Wall Anchors Pre Assembled M8x70mm Screw Size
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Hollow Wall Anchors
Price: 0.02 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Hollow Wall Anchors
MOQ:	100 Pieces
Price:	USD 0.02-0.15 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Dia:

12mm

Plug Length:

70mm

Screw Size:

M8x70mm

Drill Hole:

12mm

Screw Material:

Zinc Steel

Anchor Type:

Wing Expand

Substrate:

Cavity Wall

Color:

Yellow, OEM

Measurement:

Metric

Pack:

Pre-Assembled

Corrosion:

Zinc-Plated

Load Class:

Max Capacity

Use Case:

TV Bracket

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

plastic toggle wall anchors pre assembled

m8x70mm plastic toggle wall anchors

m8x70mm winged plastic wall anchors

Product Description

TV Wall Mount Hollow Wall Heavy Duty Wing Anchor Nylon Cavity Wall Fixing

Product Description

This PA6 Nylon Hollow Wall Heavy Duty Wing Anchor is a maximum-capacity fastening solution engineered for TV wall mounts, monitor brackets, and heavy wall-mounted electronic fixtures on plasterboard, hollow brick, and cavity wall substrates. Each anchor includes a 12mm diameter PA6 nylon expanding wing plug pre-matched with an M8 x 70mm zinc-plated self-tapping screw, delivering the highest load capacity available for hollow wall anchoring applications.

The installation follows the reliable hollow wall anchoring principle: drill a 12mm hole at each TV bracket mounting position, insert the nylon plug until the flange is flush with the wall surface, position the TV wall mount bracket, and drive the M8 screw through the bracket into the plug. As the screw advances to full depth, it compresses the nylon body and triggers the oversized internal folding wings to spread outward behind the wall cavity. These wings open fully to form an exceptionally large rear bearing surface, creating a powerful positive mechanical lock against the back of the plasterboard or hollow brick that securely supports the substantial weight of modern flat-screen televisions.

The nylon material combines outstanding toughness with superior aging resistance, maintaining full wing expansion force and structural integrity through years of static television weight loading. The nylon body is electrically non-conductive, providing an additional safety advantage when mounting near hidden wall wiring and power cables. The M8 screw with 70mm extended body length accommodates thicker wall cavities with plaster depth up to 40mm, while the oversized 12mm wing span provides the maximum rear contact area available for hollow wall anchoring.

Features

Maximum Rear Wing Span: The 12mm diameter plug features the largest wing span in the hollow wall anchor series, deploying oversized folding wings that create an exceptionally wide rear bearing surface behind the wall cavity. This wide-area rear grip securely supports heavy flat-screen televisions by distributing weight across the maximum possible contact area, preventing pull-out failure risk.

TV-Grade Heavy Loading: Engineered and tested specifically for television wall mount applications, the M8 screw with 70mm deep anchoring delivers dependable load capacity of up to 50kg in 12.5mm plasterboard and up to 70kg in hollow brick. The robust wing expansion mechanism provides the confident holding power needed for expensive electronic wall-mounted fixtures.

Non-Conductive Safety Barrier: The 100% nylon plug body acts as a natural electrical insulator between the metal mounting screw and surrounding wall material. This provides essential electric safety protection when mounting televisions near power outlets and in-wall cabling, eliminating any possibility of current conduction through the fastener system to the metal TV bracket.

Technical Parameters

General Information
Product Name	Plastic Hollow Wall Anchors / Cavity Wall Fixing Set
Plug Diameter	12mm
Plug Length	70mm
Screw Diameter	M8
Screw Length	70mm
Pre-drill Hole Diameter	12mm
Min. Wall Thickness	10mm
Plug Material	Nylon PA6 / Polypropylene Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel 304
Color Options	Yellow, White, Grey, Blue, Red, OEM
Anchor Type	Hollow Wall Self-Expanding Wing Anchor
Installation Method	Pre-drill → insert plug → drive screw → auto-expand anchor
Load Capacity (Drywall 12.5mm)	Up to 50kg
Load Capacity (Hollow Brick)	Up to 70kg
Temperature Range	-30°C to +70°C
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

TV Wall Mount Hollow Plastic Toggle Wall Anchors Pre Assembled M8x70mm Screw Size

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
