Grab Bar Handrail Hollow Winged Drywall Anchor M8x75mm Nylon Safety Wall Mounting

Name: Grab Bar Handrail Hollow Winged Drywall Anchor M8x75mm Nylon Safety Wall Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Hollow Wall Anchors
Price: 0.02 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Hollow Wall Anchors
MOQ:	100 Pieces
Price:	USD 0.02-0.15 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Material:

Nylon PA6

Plug Dia:

12mm

Plug Length:

75mm

Screw Size:

M8x75mm

Drill Hole:

12mm

Screw Material:

Zinc Steel

Anchor Type:

Wing Expand

Substrate:

Hollow Brick

Color:

Yellow, OEM

Measurement:

Metric

Pack:

Pre-Assembled

Corrosion:

Heavy Zinc

Load Class:

Safety Rated

Use Case:

Grab Bar

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

winged drywall anchor m8x75mm

handrail winged drywall anchor

handrail winged plastic anchor

Product Description

Grab Bar Handrail Hollow Wall Max Wing Anchor Nylon Safety Wall Mounting

Product Description

This PA6 Nylon Hollow Wall Max Strength Wing Anchor is a safety-critical maximum-capacity fastening solution engineered for bathroom grab bars, handrails, disability support rails, and elderly care safety fixtures on hollow brick, plasterboard, and cavity wall substrates. Each anchor includes a 12mm diameter PA6 nylon expanding wing plug pre-matched with an M8 x 75mm zinc-plated self-tapping screw, providing the highest safety-rated load capacity in the hollow wall anchor series.

The installation follows the safety-critical hollow wall anchoring principle: drill a 12mm hole at each grab bar bracket position, carefully clean the hole of all drilling debris, insert the nylon plug until the flange is flush with the wall surface, position the grab bar bracket, and drive the M8 screw through the bracket into the plug. As the screw reaches full insertion depth, it compresses the nylon body and triggers the oversized internal wings to fully spread behind the wall cavity, creating a powerful positive mechanical lock. The 75mm extended body length deploys the largest wings in the series, forming a maximum rear bearing surface that reliably supports the body weight loads demanded by bathroom safety fixtures.

The nylon formulation is engineered for safety-critical reliability with outstanding toughness and impact resistance. The nylon plug body is completely waterproof, never rusting or corroding in the perpetually humid bathroom environment. It maintains full mechanical integrity and wing expansion force through thousands of load cycles over decades of grab bar service. The oversized M8 screw with heavy-duty zinc plating provides the robust tensile strength needed for safety handrail applications where human safety depends on anchor reliability.

Features

Safety-Rated Maximum Load: Independently tested and rated for safety-critical applications, the M8 screw with 75mm anchoring depth delivers the highest hollow wall load capacity available: up to 60kg in 12.5mm plasterboard and up to 85kg in hollow brick. This safety-rated capacity provides the confidence required for bathroom grab bars and disability handrails where human body weight support is essential.

Oversized Safety Wing Span: The 75mm extended plug body deploys the largest folding wings in the hollow wall anchor range, creating a rear bearing surface area up to 3x larger than standard wing anchors. This wide-area rear grip distributes body-weight loads across the maximum possible wall contact area, significantly reducing point-load stress and eliminating pull-out risk in safety applications.

Lifetime Waterproof Reliability: The nylon plug body is formulated for permanent bathroom installation with zero degradation from constant humidity, steam, cleaning chemicals, and water exposure. It maintains 100% of its wing expansion holding force through decades of continuous grab bar service, providing lifetime safety reliability without the hidden corrosion degradation that can compromise metal anchors in bathroom walls.

Technical Parameters

General Information
Product Name	Plastic Hollow Wall Anchors / Cavity Wall Fixing Set
Plug Diameter	12mm
Plug Length	75mm
Screw Diameter	M8
Screw Length	75mm
Pre-drill Hole Diameter	12mm
Min. Wall Thickness	12mm
Plug Material	Nylon PA6 / Polypropylene Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel 304
Color Options	Yellow, White, Grey, Blue, Red, OEM
Anchor Type	Hollow Wall Self-Expanding Wing Anchor
Installation Method	Pre-drill → insert plug → drive screw → auto-expand anchor
Load Capacity (Drywall 12.5mm)	Up to 60kg
Load Capacity (Hollow Brick)	Up to 85kg
Temperature Range	-30°C to +70°C
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Grab Bar Handrail Hollow Winged Drywall Anchor M8x75mm Nylon Safety Wall Mounting

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
