Shelf Bracket Plastic Hollow Wall Anchors Nylon Plasterboard Mounting Plastic Wing Anchors

Name: Shelf Bracket Plastic Hollow Wall Anchors Nylon Plasterboard Mounting Plastic Wing Anchors
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Hollow Wall Anchors
Price: 0.02 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Hollow Wall Anchors
MOQ:	100 Pieces
Price:	USD 0.02-0.15 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Material:

Nylon PA6

Plug Dia:

8mm

Plug Length:

50mm

Screw Size:

M5x50mm

Drill Hole:

8mm

Screw Material:

Zinc Steel

Anchor Type:

Wing Expand

Substrate:

Hollow Brick

Color:

Yellow, OEM

Measurement:

Metric

Pack:

Pre-Assembled

Corrosion:

Zinc-Plated

Cavity:

Deep Wing

Use Case:

Shelf Bracket

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

shelf bracket plastic hollow wall anchors

plasterboard plastic wing anchors

plasterboard plastic hollow wall anchors

Product Description

Shelf Bracket Hollow Wall Expandable Wing Anchor Nylon Plasterboard Mounting

Product Description

This PA6 Nylon Hollow Wall Expandable Wing Anchor Kit is a medium-duty fastening solution engineered for shelf brackets, storage racks, and wall-mounted shelving systems on plasterboard, drywall, and hollow brick substrates. Each anchor includes an 8mm diameter nylon expanding wing plug factory-matched with an M5 x 50mm zinc-plated self-tapping screw, providing reliable holding power for everyday shelving applications.

The installation follows the proven hollow wall anchoring principle: drill an 8mm hole at each shelf bracket mounting position, insert the nylon plug until the flange is flush with the wall surface, align the shelf bracket, and drive the M5 screw through the bracket into the plug. As the screw advances, it compresses the nylon body, triggering the internal folding wings to expand outward behind the wall cavity. These wings spread to form a large rear bearing surface, creating a positive mechanical lock against the back of the plasterboard or hollow brick that distributes the shelf load over a much wider area than simple friction-based plugs. The 50mm extended plug body provides a deep anchoring zone suitable for walls with cavities up to 25mm.

Manufactured from high-toughness nylon with excellent aging and corrosion resistance, the plug body is completely immune to rust, moisture absorption, and environmental degradation. The zinc-plated steel screw provides dependable fastening strength with atmospheric corrosion protection. This combination ensures the shelf remains securely anchored through years of daily loading and unloading without any deterioration in holding performance, making it ideal for kitchen shelving, pantry racks, and garage storage systems.

Features

Deep Cavity Wing Lock: The 50mm extended plug body with internal folding wings creates an exceptionally deep anchoring zone, allowing the wings to fully deploy behind even thick plasterboard and hollow brick wall cavities. Once expanded, the large rear wing surface provides a positive mechanical lock that distributes shelf bracket loads evenly, preventing localized wall material crushing and anchor pull-out under sustained weight.

Corrosion-Free Nylon Body: The nylon plug is 100% rust-proof and completely resistant to moisture-induced swelling or degradation. Unlike metal cavity anchors that can corrode from within the wall, the nylon body maintains its full wing expansion integrity in humid environments such as kitchens, laundry rooms, and basements, ensuring the shelf remains securely anchored for years without hidden fastener deterioration.

Quick Plug-and-Screw Installation: The pre-assembled format eliminates the need to source and verify screw compatibility separately. Simply drill the hole, insert the plug, position the shelf bracket, and drive the screw until the wings fully expand behind the wall surface. The entire installation requires only a drill and screwdriver, enabling rapid multi-bracket shelf mounting without special setting tools or expansion guns.

Technical Parameters

General Information
Product Name	Plastic Hollow Wall Anchors / Cavity Wall Fixing Set
Plug Diameter	8mm
Plug Length	50mm
Screw Diameter	M5
Screw Length	50mm
Pre-drill Hole Diameter	8mm
Min. Wall Thickness	5mm
Plug Material	Nylon PA6 / Polypropylene Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel 304
Color Options	Yellow, White, Grey, Blue, Red, OEM
Anchor Type	Hollow Wall Self-Expanding Wing Anchor
Installation Method	Pre-drill → insert plug → drive screw → auto-expand anchor
Load Capacity (Drywall 12.5mm)	Up to 25kg
Load Capacity (Hollow Brick)	Up to 35kg
Temperature Range	-30°C to +70°C
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Shelf Bracket Plastic Hollow Wall Anchors Nylon Plasterboard Mounting Plastic Wing Anchors

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
