Hammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail Anchor

Hammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail Anchor

Brand Name: CangRui
Model Number: Plastic Wall Plug
MOQ: 5000 Pieces
Price: USD 0.008 - 0.04 / Piece
Payment Terms: T/T,L/C,PayPal,Western Union
Supply Ability: 4000000 Pieces per Month
Detail Information
Place of Origin:
Hebei, China
Certification:
ISO9001
Sizes:
5mm, 6mm, 8mm, 10mm
Pin Type:
Pre-assembled Steel Nail
Application:
Quick Fixing, Solid Wall, One-step Install
Installation:
Drill, Insert Plug, Hammer Pin Flush
Body:
Standard Expansion With Pre-inserted Pin
Anchor Type:
Hammer Drive Wall Plug
Material:
Nylon PA6 + Steel Nail
Install Tool:
Hammer Only, No Screwdriver
Finish Type:
Flush Pin Finish
Packaging Details:
WNRLN polybag with size label, export-grade corrugated carton
Highlight:

nylon plastic wall plugs for screws

,

plastic wall plugs for screws pre assembled

,

nylon plastic wall plugs for plasterboard

Product Description

Hammer Drive Nylon Plastic Wall Plug Pre-Assembled Nail Anchor Pin Insert for Quick Solid Wall Fixing




Product Description



The Hammer Drive Nylon Plastic Wall Plug is a pre-assembled anchor system that combines a nylon PA6 expansion plug body with a factory-inserted steel nail pin, enabling true one-step installation with only a hammer. No screwdriver, drill driver, or power tool is needed for the fastening step. The operator simply drills a clean hole to the specified diameter, inserts the pre-assembled plug flush with the wall surface, and strikes the protruding nail head with a standard claw hammer until it sits flush. The nail drives through the plug body, forcing radial expansion against the borehole wall for a secure, permanent anchor point.



The steel nail pin is zinc-plated for corrosion resistance and features a flat countersunk head that finishes flush with the plug collar when fully seated. The head provides a clean, snag-free surface profile suitable for wall fixtures, junction boxes, conduit clips, and trim applications where an exposed screw head would be visually undesirable or interfere with the mounted fixture.



Molded from high-toughness nylon PA6 engineering plastic, the plug body delivers excellent tensile strength and deformation resistance. The material is completely rust-proof with proven acid and alkali chemical resistance, ensuring reliable long-term performance in bathrooms, kitchens, and outdoor environments. Unlike traditional screw-and-plug systems, the hammer-set design eliminates the risk of screw cam-out, stripped threads, and inconsistent torque that can compromise holding strength.



Installation is the fastest of any plastic wall plug system: drill a clean hole to the specified diameter, remove bulk drilling dust, push the pre-assembled plug in flush, and hammer the nail head until it sits flush with the plug collar. The entire fastening cycle takes seconds per anchor point, making it ideal for high-volume electrical rough-in, drywall installation, and construction fix-out where speed is critical.



Features





Pre-Assembled One-Piece Design: Steel nail pin is factory-inserted into the nylon plug body, eliminating the separate step of loading a screw onto a driver bit. One SKU for the complete anchoring system.

Hammer-Only Installation: No screwdriver, electric drill driver, or impact driver required for the fastening step. A standard claw hammer is the only tool needed to set the anchor after drilling the hole.

Instant Expansion Anchoring: A single hammer strike on the nail drives it through the plug body, forcing immediate and uniform radial expansion against the borehole wall for positive mechanical lock.

Flush Countersunk Finish: The zinc-plated steel nail head sits flush with the plug collar when fully seated, providing a clean snag-free surface that does not interfere with mounted fixtures or create visible protrusion.

Rust-Free Dual-Material System: Nylon PA6 plug body with zinc-plated steel nail pin delivers corrosion resistance for indoor and sheltered outdoor use. Nylon body resists acid and alkali chemical exposure.


Technical Parameters





General Information
Product Name Hammer Drive Nylon Plastic Wall Plug
Material Nylon PA6 engineering grade + zinc-plated steel nail
Body Standard expansion with pre-inserted nail pin
Color Natural, White, Grey, Custom
Dimensions & Compatibility
Sizes 5mm, 6mm, 8mm, 10mm (standard)
Plug Length 25mm, 30mm, 35mm, 40mm, 50mm
Drill Bit Diameter Match plug diameter
Screw Compatibility Pre-assembled nail pin (3-5mm diameter by plug size)
Installation
Method Drill hole → remove dust → insert plug flush → hammer nail head until flush
Tool Hammer only (claw hammer recommended)
Key Feature Pre-assembled nail pin enables one-step hammer-set installation without screwdriver
Fastening Type Through-fastening
Performance
Pull-Out (M6 Concrete) 60 kg
Pull-Out (M8 Solid Brick) 45 kg
Shear Strength (Zinc Nail) 180 N (M6), 250 N (M8)
Temperature Range -20°C to +80°C
Environmental Resistance Rust-free plug body, zinc-plated nail, acid-alkali resistant
Compliance RoHS Compliant, REACH Compliant
Standards ISO 9001:2015
Application
Applicable Substrates Solid brick, concrete (uncracked), stone, blockwork, aerated concrete
Common Applications Electrical junction boxes, conduit clips, cable management trays, skirting board fixing, door frame trim, wall panel clips, light-duty bracket mounting, batch construction fix-out
Usage Restriction Not for overhead or critical load applications; nail must be driven fully flush for full expansion
Packaging
Standard Packaging 100 / 200 / 300 pieces per polybag with size label
Bulk Packaging Export-grade corrugated carton, 20-50 bags per carton
Screws Included Screws sold separately
Certifications ISO 9001:2015





Hammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail AnchorHammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail Anchor

Hammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail Anchor

Hammer Drive Nylon Plastic Wall Plugs For Screws Pre Assembled Nail Anchor



FAQ



Do you have full standard sizes in stock for plastic expansion anchors?


We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.



What is the material and load-bearing capacity of your Plastic insulation anchors?


Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.



What types of walls and base materials can this Plastic insulation anchors be used for?


It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.



What is your MOQ and wholesale price discount policy?


Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.



What is your production lead time and mass supply capacity?


Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.



Can you customize size, color, packaging and OEM private label?


We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.



Do you support mixed batch with other fastener products?


Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.



Can I get free samples for quality checking?


Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
