Cable Tray Conduit Wall Plastic Expansion Anchors M5 Multi Purpose Electrical Fastener

Name: Cable Tray Conduit Wall Plastic Expansion Anchors M5 Multi Purpose Electrical Fastener
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Screw
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Screw
MOQ:	100 Pieces
Price:	USD 0.03-0.12 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Material:

Nylon PA6

Substrate:

Multi-Wall

Screw Size:

M5x50mm

Plug Length:

50mm

Color:

Yellow, OEM

Measurement:

Metric

Corrosion:

Zinc-Plated

Drill Hole:

8mm

Screw Material:

Zinc Steel

Pack Type:

Pre-Assembled

Fastener Type:

Expansion Screw

Mount Type:

Bracket Fix

Environment:

Indoor/Outdoor

Plug Dia:

8mm

Use Case:

Cable Tray

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

plastic expansion anchors m5

conduit expansion screw plastic

conduit plastic expansion anchors

Product Description

Cable Tray Conduit Wall Plastic Expansion Screw Anchor Nylon PA6 M5 Multi-Purpose Electrical Fastener Kit

Product Description

The Nylon Plastic Expansion Screw Cable Tray Conduit Bracket Fastener is a versatile multi-purpose fastening solution specifically designed for electrical cable trays, PVC conduit straps, metal trunking brackets, and various electrical installation support hardware on brick, concrete, hollow block, and drywall substrates. Each complete set contains an 8mm diameter PA6 nylon expansion plug pre-matched with an M5 x 50mm zinc-plated steel screw, delivering universal compatibility across diverse electrical installation scenarios.

The installation follows the proven plastic expansion principle: select the correct drill bit matching the 8mm plug diameter, drill an 8mm hole to 60mm depth at each cable tray or conduit bracket mounting position, insert the nylon plug until the collar sits flush with the wall surface, position the cable tray bracket or conduit strap, then drive the M5 screw through the bracket into the plug. As the screw advances to full depth, the cone-shaped tail section forces the nylon body to expand radially outward against the drill hole wall, using the friction generated by the screw spreading the plug to create a tight locking grip in the substrate. The nylon plug body is completely rust-proof and resistant to moisture absorption, ensuring reliable long-term fastening performance in basements, utility rooms, outdoor electrical enclosures, and other environments where metal anchors would eventually corrode.

Designed for the cost-conscious electrical contractor and volume installer, this fastener is available in economy bulk pack quantities with competitive wholesale pricing. The 50mm extended plug body provides a deep expansion zone that delivers consistent holding power across multiple substrate types - from solid concrete walls in commercial electrical rooms to hollow brick and drywall partitions in residential wiring projects. The universal M5 screw head style is compatible with standard Phillips and Pozidriv screwdrivers used on every electrical installation site, requiring no special tools or bits for installation.

Features

Multi-Purpose Tray Anchor

The 8mm plug with M5 screw combination is engineered to securely mount the most common sizes of PVC and metal cable trays, conduit straps, and trunking brackets found in residential, commercial, and light industrial electrical installations. One fastener type covers multiple electrical mounting applications, reducing the variety of anchors electrical contractors need to stock and carry to each job site.

Cost-Effective Bulk Fastening

Available in cost-optimized bulk quantities of 500, 1000, or 5000+ pieces per carton, this fastener delivers exceptional per-unit value for electrical contractors, wholesale distributors, and volume purchasers. The competitive pricing combined with professional-grade PA6 nylon and zinc-plated steel construction makes it the practical choice for large-scale electrical installation projects where hundreds or thousands of anchor points are required.

All-Environment Plastic Plug

The 100% rust-proof PA6 nylon plug functions reliably in damp basements, humid utility spaces, outdoor electrical enclosures, and areas subject to occasional water exposure where traditional metal anchors would eventually corrode and fail. The nylon material never rusts, never swells from moisture absorption, and maintains its full mechanical expansion properties across the complete operating temperature range from -40°C to +80°C, providing dependable anchoring in any indoor or outdoor electrical installation environment.

Technical Parameters

General Information
Product Name	Plastic Expansion Screw (Nylon Plug + Matching Screw Set)
Plug Diameter	8mm
Plug Length	50mm
Screw Diameter	M5
Screw Length	50mm
Pre-drill Hole Diameter	8mm
Plug Material	Nylon PA6 / Polyamide Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel (Optional)
Color Options	Yellow, White, Grey, Blue, OEM Custom
Installation Method	Select drill bit → drill hole → insert plug → drive screw → expansion lock
Load Capacity (Solid Concrete)	Up to 55kg
Load Capacity (Hollow Brick)	Up to 22kg
Temperature Range	-40°C to +80°C (PA6 nylon)
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Cable Tray Conduit Wall Plastic Expansion Anchors M5 Multi Purpose Electrical Fastener

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
