Outdoor Weatherproof Plastic Expansion Screw Kit Window Frame Exterior Wall Installation

Name: Outdoor Weatherproof Plastic Expansion Screw Kit Window Frame Exterior Wall Installation
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Screw
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Screw
MOQ:	100 Pieces
Price:	USD 0.03-0.12 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Dia:

6mm

Plug Length:

40mm

Screw Size:

M5x40mm

Drill Hole:

6mm

Plug Material:

Nylon PA6

Screw Material:

Zinc Steel HD

Color:

Yellow, OEM

Fastener Type:

Expansion Screw

Substrate:

Multi-Wall

Use Case:

Window Frame

Weather Rating:

Outdoor Grade

Measurement:

Metric

Pack Type:

Pre-Assembled

Corrosion:

Heavy Zinc

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

weatherproof plastic expansion screw

outdoor plastic expansion screw

outdoor expanding plastic screw anchors

Product Description

Outdoor Weatherproof Nylon Expansion Screw Anchor Kit Window Frame Exterior Wall Installation Fastener

Product Description

The Outdoor Weatherproof Nylon Expansion Screw Anchor Kit is a weather-resistant fastening solution engineered for window frames, exterior trim, and outdoor wall fixtures that are exposed to temperature fluctuations, rain, and moisture throughout the seasons. Each complete set includes a 6mm diameter PA6 nylon expansion plug factory-matched with an M5 x 40mm zinc-plated steel screw featuring enhanced corrosion protection for demanding outdoor use.

Installation follows the reliable expansion principle: drill a 6mm hole through the window frame mounting bracket and into the wall substrate, insert the nylon plug until the collar sits flush against the surface, align the window frame bracket, and drive the M5 screw through the bracket into the plug. The screw's cone-shaped tail expands the nylon body radially against the hole wall, creating a secure friction lock that anchors the window frame firmly in place. The nylon plug body is 100% rust-proof and completely unaffected by moisture absorption, while the heavy-duty zinc-plated screw provides dependable atmospheric corrosion resistance - together they deliver reliable long-term outdoor fastening performance.

Features

Weather-Resistant Zinc Screw

The M5 steel screw features heavy-duty zinc electroplating that forms a protective barrier against atmospheric moisture and rain exposure, effectively preventing rust formation. This ensures the screw remains serviceable for removal and retightening even after years of outdoor exposure on window frames and exterior architectural trim.

Indoor Outdoor Versatility

The combination of a 100% rust-proof nylon plug and corrosion-resistant zinc-plated screw makes this fastener equally reliable for interior window frames in humid bathrooms and kitchens as well as exterior window installations fully exposed to direct weather conditions, rain, and UV radiation throughout all seasons.

Multi-Substrate Grip

The 40mm plug body with 6mm diameter provides a generous expansion zone that delivers consistent and dependable holding power across multiple substrate types - solid brick, hollow brick, concrete, aerated concrete, and plasterboard - making it the universal one-fastener solution for varied window frame installation conditions encountered on construction sites.

Technical Parameters

General Information
Product Name	Plastic Expansion Screw (Nylon Plug + Matching Screw Set)
Plug Diameter	6mm
Plug Length	40mm
Screw Diameter	M5
Screw Length	40mm
Pre-drill Hole Diameter	6mm
Plug Material	Nylon PA6 / Polyamide Engineering Plastic
Screw Material	Carbon Steel (Heavy Zinc-Plated) / Stainless Steel (Optional)
Color Options	Yellow, White, Grey, Blue, OEM Custom
Installation Method	Pre-drill → insert plug → drive screw → expansion lock
Load Capacity (Solid Brick)	Up to 40kg
Load Capacity (Hollow Brick)	Up to 20kg
Temperature Range	-40°C to +80°C (PA6 nylon)
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Outdoor Weatherproof Plastic Expansion Screw Kit Window Frame Exterior Wall Installation

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
