Heavy Load Nylon Expansion Screw Plastic M6x50mm Door Frame Assembly

Name: Heavy Load Nylon Expansion Screw Plastic M6x50mm Door Frame Assembly
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Screw
Price: 0.04 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Screw
MOQ:	100 Pieces
Price:	USD 0.04-0.15 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Dia:

8mm

Plug Length:

50mm

Screw Size:

M6x50mm

Drill Hole:

8mm

Plug Material:

Nylon PA6

Screw Material:

Zinc Steel

Color:

Yellow, OEM

Fastener Type:

Expansion Screw

Substrate:

Solid Wall

Use Case:

Door Frame

Load Class:

Heavy Duty

Measurement:

Metric

Pack Type:

Pre-Assembled

Corrosion:

Zinc-Plated

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

nylon expansion screw plastic

expansion screw plastic m6x50mm

nylon plastic expansion anchors

Product Description

Heavy-Load Nylon Plastic Wall Expansion Screw Door Frame Assembly Complete Anchor Fastener Kit

Product Description

The Heavy-Load Nylon Plastic Wall Expansion Screw is a heavy-duty fastening solution designed for door frames, structural wall assemblies, and load-bearing wall fixtures on solid brick and concrete substrates. Each complete set contains an 8mm diameter PA6 nylon expansion plug pre-matched with an M6 x 50mm zinc-plated steel screw, providing robust fastening capacity for demanding structural applications.

Installation follows the established expansion principle: drill an 8mm hole to the required depth in the solid wall substrate, thoroughly clean the hole of drilling dust and debris, insert the nylon plug until its collar sits flush with the wall surface, align the door frame bracket, and drive the M6 screw through the bracket into the plug. As the screw reaches full insertion depth, the cone-shaped tail section forces the nylon plug body to expand radially against the hole wall, creating a powerful friction lock capable of supporting the substantial weight of solid timber door frames and wall-mounted structural assemblies. The impact-resistant PA6 nylon formulation withstands the high installation torque required for structural fixing without cracking or deforming under load.

Features

Heavy Load Door Frame

The M6 screw with extended 50mm plug length provides the exceptional load capacity required for solid timber door frames, heavy wall-mounted assemblies, and structural brackets. The deep 50mm expansion zone engages a large load-bearing contact area within the substrate, distributing forces evenly to prevent localized wall material failure.

Impact-Resistant PA6 Body

The nylon plug is formulated from high-toughness PA6 engineering plastic with enhanced impact resistance that prevents cracking under the high installation torque and sudden load forces typical of structural fixing applications. This impact-modified formulation maintains full structural integrity even when driven into slightly undersized or irregular drill holes.

Deep Thread Expansion Lock

The extended 50mm plug body provides a proportionally deep expansion zone that engages the full thread length of the M6 screw. This deep expansion lock creates multiple friction contact points distributed along the entire hole depth, delivering a significantly more secure and vibration-resistant fixing compared to shorter standard plugs.

Technical Parameters

General Information
Product Name	Plastic Expansion Screw (Nylon Plug + Matching Screw Set)
Plug Diameter	8mm
Plug Length	50mm
Screw Diameter	M6
Screw Length	50mm
Pre-drill Hole Diameter	8mm
Plug Material	Nylon PA6 / Polyamide Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel (Optional)
Color Options	Yellow, White, Grey, Blue, OEM Custom
Installation Method	Pre-drill → insert plug → drive screw → expansion lock
Load Capacity (Solid Concrete)	Up to 80kg
Load Capacity (Solid Brick)	Up to 55kg
Temperature Range	-40°C to +80°C (PA6 nylon)
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Heavy Load Nylon Expansion Screw Plastic M6x50mm Door Frame Assembly

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
