Industrial Grade Nylon Expanding Screws Pipe Clamp Bracket Concrete Wall Mounting

Name: Industrial Grade Nylon Expanding Screws Pipe Clamp Bracket Concrete Wall Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Screw
Price: 0.05 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Screw
MOQ:	100 Pieces
Price:	USD 0.05-0.20 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Plug Dia:

10mm

Plug Length:

60mm

Screw Size:

M8x60mm

Drill Hole:

10mm

Plug Material:

Nylon PA6

Screw Material:

Zinc Steel

Color:

Yellow, OEM

Fastener Type:

Expansion Screw

Substrate:

Concrete

Use Case:

Pipe Clamp

Temp Range:

-40 To +80°C

Measurement:

Metric

Pack Type:

Pre-Assembled

Corrosion:

Zinc-Plated

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

nylon plastic expansion screw

nylon expanding plastic screw anchors

industrial grade plastic expansion screw

Product Description

Industrial Grade Nylon Expansion Screw Anchor Pipe Clamp Bracket Concrete Wall Mounting Fastener Kit

Product Description

The Industrial Grade Nylon Expansion Screw Anchor is an industrial-strength fastening solution designed for pipe clamps, conduit brackets, HVAC duct supports, and heavy mechanical bracket mounting on solid concrete and masonry substrates. Each complete set contains a 10mm diameter PA6 nylon expansion plug pre-matched with an M8 x 60mm zinc-plated steel screw, delivering industrial-level holding power for demanding mechanical and plumbing installations.

Installation follows the classic expansion principle: drill a 10mm hole to the full required depth in the concrete or masonry substrate, thoroughly clean the hole of all drilling dust and debris, insert the nylon plug until its collar is flush with the wall surface, align the pipe clamp bracket, and drive the M8 screw through the bracket into the plug. As the screw reaches full insertion depth, the cone-shaped tail section forces the nylon body to expand radially, creating a powerful friction lock distributed along the entire 60mm plug length. The temperature-tolerant PA6 nylon maintains its full mechanical properties across a wide operating range from -40°C to +80°C, making it equally suitable for heated indoor mechanical rooms and outdoor exposed pipe runs.

Features

Wide Load Distribution

The 10mm diameter plug with extended 60mm body length creates an exceptionally large expansion contact area within the substrate, effectively distributing pipe clamp and mechanical bracket loads across a wide bearing surface. This wide distribution prevents localized concrete crushing and anchor pull-out failure under sustained static and dynamic mechanical loads.

Temperature Tolerant Nylon

The PA6 nylon formulation maintains full expansion grip and mechanical strength across a broad temperature range from -40°C to +80°C, making this fastener reliably suitable for outdoor pipe runs exposed to seasonal temperature extremes and indoor mechanical rooms with elevated ambient operating temperatures around HVAC equipment.

Industrial Pipe Mounting

Engineered specifically for the demanding requirements of industrial pipe and conduit installation, the M8 screw with 60mm plug depth provides the high load capacity and vibration resistance needed for securing pipe clamps, conduit straps, and HVAC duct mounting brackets to concrete and masonry walls in commercial and industrial buildings.

Technical Parameters

General Information
Product Name	Plastic Expansion Screw (Nylon Plug + Matching Screw Set)
Plug Diameter	10mm
Plug Length	60mm
Screw Diameter	M8
Screw Length	60mm
Pre-drill Hole Diameter	10mm
Plug Material	Nylon PA6 / Polyamide Engineering Plastic
Screw Material	Carbon Steel (Zinc-Plated) / Stainless Steel (Optional)
Color Options	Yellow, White, Grey, Blue, OEM Custom
Installation Method	Pre-drill → insert plug → drive screw → expansion lock
Load Capacity (Solid Concrete)	Up to 120kg
Load Capacity (Solid Brick)	Up to 75kg
Temperature Range	-40°C to +80°C (PA6 nylon)
Compliance	RoHS Compliant, REACH Compliant
Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag

Industrial Grade Nylon Expanding Screws Pipe Clamp Bracket Concrete Wall Mounting

FAQ

Q: Do you have full standard sizes in stock for plastic expansion anchors?

A: We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

Q: What is the material and load-bearing capacity of your Plastic insulation anchors?

A: Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

Q: What types of walls and base materials can this wall plug be used for?

A: It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

Q: What is your MOQ and wholesale price discount policy?

A: Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

Q: What is your production lead time and mass supply capacity?

A: Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Q: Can you customize size, color, packaging and OEM private label?

A: We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Q: Do you support mixed batch with other fastener products?

A: Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Q: Can I get free samples for quality checking?

A: Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
