Dual Layer Nylon Universal Wall Plugs For Heavy Mirror Double Drywall Fixing

Name: Dual Layer Nylon Universal Wall Plugs For Heavy Mirror Double Drywall Fixing
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Universal Wall Plugs
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Universal Wall Plugs
MOQ:	100 Pieces
Price:	USD 0.03-0.20 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Material:

Nylon PA6

Finish:

Bright(Uncoated)

Color:

White, Grey, OEM

Fastener Type:

Four-Wing Sleeve Anchor

Wing Count:

4 Wings

Measurement System:

Metric

Connection Method:

Bolt Joint

Corrosion Proof:

100% Rust-Free

Screw Size:

M10

Anchor Length:

70mm

Drill Hole:

14mm

Use Case:

Heavy Mirrors

Wall Type:

Double-Layer

Substrate:

Double Drywall

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

nylon universal wall plugs

nylon universal wall plug plasterboard

m10 universal wall plugs

Product Description

Dual-Layer Nylon Four-Wing Knot Expansion Wall Anchor Plastic Plug for Heavy Mirror Double Drywall Fixing

Product Description

The M10 x 70mm Nylon Four-Wing Knot Expansion Wall Plug is a dual-layer plastic fastening solution engineered for heavy mirrors, large wall art, and oversized decorative panels on double-layer drywall and thick plasterboard surfaces. The anchor features a premium four-wing knot-expansion body made from industrial-grade PA6 nylon, with a 70mm body length that penetrates through both drywall layers into the cavity beyond. When the M10 screw is driven in, the four wings deploy across a 32mm diameter behind the inner drywall layer, creating a knot-lock that anchors through the full wall assembly. Installation requires only a drill, screwdriver, and the anchor itself - no special tools needed. Drill a 14mm hole through both drywall layers, insert the anchor until flush, and drive the M10 screw to activate the full knot-expansion mechanism.

Features

Dual-Layer Wall Anchoring - The 70mm extended body penetrates through both layers of double drywall construction, deploying the four-wing knot-lock behind the inner board for maximum holding power in thick wall assemblies.

Extra-High Shear Strength - With up to 95kg shear capacity in 12.5mm plasterboard and a 32mm wing span, this is the highest-capacity anchor in the UW series, built for the heaviest wall-mounted mirrors and decorative panels.

No Special Tools Required - Complete installation requires only a standard drill with 14mm masonry bit and a Phillips screwdriver - no setting tools, expansion guns, or specialized installation equipment needed.

32mm Maximum Wing Expansion - The broadest wing deployment in the UW product line creates the largest possible bearing surface behind double drywall, safely distributing the concentrated weight of oversized mirrors and heavy wall art.

Technical Parameters

General Information
Product Name	Nylon Four-Wing Knot Expansion Wall Plug UW Series
Screw Diameter	M10
Anchor Length	70mm
Wing Count	4 Wings
Material	Nylon PA6 / Polyamide Engineering Plastic
Color Options	White, Grey, Blue, Natural (customizable)
Anchor Structure	Four-wing folding body with knot-expansion mechanism
Dimensions & Compatibility
Drill Hole Diameter	14mm
Min Embedment Depth	73mm
Wing Expansion Range	14-32mm
Pre-drill Required	Yes - drill hole to recommended diameter
Recommended Drill Type	Masonry drill bit for hollow substrates
Load Capacity
Load Capacity (Plasterboard)	Up to 68kg per anchor
Load Capacity (Hollow Brick)	Up to 85kg per anchor
Pull-Out Resistance	Varies by substrate density and wing expansion depth
Shear Strength	Up to 95kg in 12.5mm plasterboard
Installation
Installation Method	Pre-drill hole → insert anchor flush → drive screw to expand wings
Installation Tool	Drill + Screwdriver / Impact driver with Phillips bit
Key Mechanism	Screw drives into anchor body forcing four wings to fold outward creating knot-lock
Anti-Rotation Feature	Ribbed body prevents spinning during screw insertion
Application
Suitable Substrates	Plasterboard, Drywall, Gypsum Board, Hollow Brick, Cavity Wall, Aerated Concrete, Lightweight Concrete
Common Uses	Heavy Mirrors and Large Wall Art on Double-Layer Drywall
Environmental & Compliance
Temperature Range	-40°C to +80°C
Environmental Suitability	Indoor and outdoor use (UV-stabilized PA6)
Corrosion Resistance	100% rust-proof plastic construction
Compliance	RoHS Compliant, REACH Compliant
Packaging
Standard Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag
Screws Included	Anchors sold separately, matching screw kits available
Certifications	ISO 9001:2015

Dual Layer Nylon Universal Wall Plugs For Heavy Mirror Double Drywall Fixing

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your plastic wall plugs?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this plastic wall plug be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling for soft substrates.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
