Wide Load Nylon Four Wing Expansion Universal Wall Plugs For Shelf Aerated Concrete Mounting

Name: Wide Load Nylon Four Wing Expansion Universal Wall Plugs For Shelf Aerated Concrete Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Universal Wall Plugs
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Universal Wall Plugs
MOQ:	100 Pieces
Price:	USD 0.03-0.20 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Material:

Nylon PA6

Finish:

Bright(Uncoated)

Color:

White, Grey, OEM

Fastener Type:

Four-Wing Sleeve Anchor

Wing Count:

4 Wings

Measurement System:

Metric

Connection Method:

Bolt Joint

Corrosion Proof:

100% Rust-Free

Screw Size:

Anchor Length:

40mm

Drill Hole:

10mm

Use Case:

Wall Shelves

Load Type:

Pull-Out Resistant

Substrate:

Aerated Concrete

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

expansion universal wall plugs

nylon universal wall plugs

nylon universal wall plug plasterboard

Product Description

Wide-Load Nylon Four-Wing Expansion Wall Plug Knot Anchor for Shelf Aerated Concrete Mounting

Product Description

The M6 x 40mm Nylon Four-Wing Knot Expansion Wall Plug is a wide-load plastic fastening solution designed for wall shelves, bookcases, and storage brackets on aerated concrete and lightweight block surfaces. The anchor features a four-wing knot-expansion body made from premium PA6 nylon that deploys across an extra-wide 22mm bearing area behind the wall surface, distributing shelf loads safely across the porous aerated substrate. The pull-out resistant design ensures shelves remain securely anchored even under the weight of books and stored items. Installation requires drilling a 10mm hole at the marked position, inserting the anchor until the collar is flush with the wall, and driving the M6 screw to expand the four wings into a secure knot-lock behind the aerated concrete face.

Features

Hollow Wall Cavity Fixing - Purpose-built for hollow and aerated substrates, the knot-expansion wings engage deep within the cavity space, creating a secure anchor point even in porous and crumbly aerated concrete blocks.

Wide Load Distribution - The four-wing design expands to a full 22mm diameter behind the wall, spreading shelf loads across a generous bearing area to prevent localized crushing of the aerated concrete substrate.

Pull-Out Resistant Design - The knot-lock mechanism resists forward pull-out forces typical of cantilevered shelf loading, maintaining secure wall engagement even under the sustained weight of books and decorative items.

Reinforced Wing Hinges - Thickened hinge points where wings meet the anchor body resist fatigue failure during repeated shelf loading and unloading, ensuring long-term structural reliability in storage applications.

Technical Parameters

General Information
Product Name	Nylon Four-Wing Knot Expansion Wall Plug UW Series
Model Number	UW-M640
Screw Diameter	M6
Anchor Length	40mm
Wing Count	4 Wings
Material	Nylon PA6 / Polyamide Engineering Plastic
Color Options	White, Grey, Blue, Natural (customizable)
Anchor Structure	Four-wing folding body with knot-expansion mechanism
Dimensions & Compatibility
Drill Hole Diameter	10mm
Min Embedment Depth	43mm
Wing Expansion Range	10-22mm
Pre-drill Required	Yes - drill hole to recommended diameter
Recommended Drill Type	Masonry drill bit for hollow substrates
Load Capacity
Load Capacity (Plasterboard)	Up to 32kg per anchor
Load Capacity (Hollow Brick)	Up to 42kg per anchor
Pull-Out Resistance	Varies by substrate density and wing expansion depth
Shear Strength	Up to 48kg in 12.5mm plasterboard
Installation
Installation Method	Pre-drill hole → insert anchor flush → drive screw to expand wings
Installation Tool	Drill + Screwdriver / Impact driver with Phillips bit
Key Mechanism	Screw drives into anchor body forcing four wings to fold outward creating knot-lock
Anti-Rotation Feature	Ribbed body prevents spinning during screw insertion
Application
Suitable Substrates	Plasterboard, Drywall, Gypsum Board, Hollow Brick, Cavity Wall, Aerated Concrete, Lightweight Concrete
Common Uses	Wall Shelves and Bookcases on Aerated Concrete
Environmental & Compliance
Temperature Range	-40°C to +80°C
Environmental Suitability	Indoor and outdoor use (UV-stabilized PA6)
Corrosion Resistance	100% rust-proof plastic construction
Compliance	RoHS Compliant, REACH Compliant
Packaging
Standard Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag
Screws Included	Anchors sold separately, matching screw kits available
Certifications	ISO 9001:2015

Wide Load Nylon Four Wing Expansion Universal Wall Plugs For Shelf Aerated Concrete Mounting

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your plastic wall plugs?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this plastic wall plug be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling for soft substrates.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
