Four Wing Knot Expansion Universal Wall Plugs Nylon Hollow Drywall Anchor For Light Picture Frame Mounting

Name: Four Wing Knot Expansion Universal Wall Plugs Nylon Hollow Drywall Anchor For Light Picture Frame Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Universal Wall Plugs
Price: 0.03 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Universal Wall Plugs
MOQ:	100 Pieces
Price:	USD 0.03-0.20 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Material:

Nylon PA6

Finish:

Bright(Uncoated)

Color:

White, Grey, OEM

Fastener Type:

Four-Wing Sleeve Anchor

Wing Count:

4 Wings

Measurement System:

Metric

Connection Method:

Bolt Joint

Corrosion Proof:

100% Rust-Free

Screw Size:

Anchor Length:

32mm

Drill Hole:

6mm

Use Case:

Picture Frames

Wing Span:

6-14mm

Substrate:

Drywall

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

expansion universal wall plugs

universal wall plugs nylon

nylon hollow drywall anchor

Product Description

Four-Wing Knot Expansion Plastic Wall Plug Nylon Hollow Drywall Anchor for Light Picture Frame Mounting

Product Description

The M4 x 32mm Nylon Four-Wing Knot Expansion Wall Plug is a lightweight plastic fastening solution designed for picture frames, small decorative items, and light fixtures on drywall and hollow wall surfaces. The anchor features a four-wing body made from durable PA6 nylon. When the M4 screw is driven into the anchor, the four wings fold outward against the inner cavity wall, creating a secure knot-style mechanical lock that firmly grips the hollow substrate. The pre-drilled installation is straightforward: drill a 6mm hole, insert the anchor flush with the wall surface, then drive the screw in until resistance increases and the wings have fully expanded behind the drywall.

Features

Four-Wing Knot Locking - The four independent wings fold outward as the screw advances, creating a knot-style lock behind the drywall surface that distributes holding force evenly across a wide area.

Quick Screw Activation - Simple screw-driven mechanism requires no special tools beyond a standard screwdriver - just insert, drive, and the wings automatically deploy into locking position.

Light-Gauge Wall Protection - The compact 32mm body length is ideal for 9.5mm and 12.5mm drywall, providing secure anchorage without risking breakthrough into wall cavities or damaging thin plasterboard.

Ribbed Anti-Spin Body - Longitudinal ribs along the anchor body grip the drill hole walls during screw insertion, preventing unwanted rotation that could compromise wing deployment alignment.

Technical Parameters

General Information
Product Name	Nylon Four-Wing Knot Expansion Wall Plug UW Series
Model Number	UW-M432
Screw Diameter	M4
Anchor Length	32mm
Wing Count	4 Wings
Material	Nylon PA6 / Polyamide Engineering Plastic
Color Options	White, Grey, Blue, Natural (customizable)
Anchor Structure	Four-wing folding body with knot-expansion mechanism
Dimensions & Compatibility
Drill Hole Diameter	6mm
Min Embedment Depth	35mm
Wing Expansion Range	6-14mm
Pre-drill Required	Yes - drill hole to recommended diameter
Recommended Drill Type	Masonry drill bit for hollow substrates
Load Capacity
Load Capacity (Plasterboard)	Up to 15kg per anchor
Load Capacity (Hollow Brick)	Up to 20kg per anchor
Pull-Out Resistance	Varies by substrate density and wing expansion depth
Shear Strength	Up to 25kg in 12.5mm plasterboard
Installation
Installation Method	Pre-drill hole → insert anchor flush → drive screw to expand wings
Installation Tool	Drill + Screwdriver / Impact driver with Phillips bit
Key Mechanism	Screw drives into anchor body forcing four wings to fold outward creating knot-lock
Anti-Rotation Feature	Ribbed body prevents spinning during screw insertion
Application
Suitable Substrates	Plasterboard, Drywall, Gypsum Board, Hollow Brick, Cavity Wall, Aerated Concrete, Lightweight Concrete
Common Uses	Small Picture Frames and Light Decor on Drywall
Environmental & Compliance
Temperature Range	-40°C to +80°C
Environmental Suitability	Indoor and outdoor use (UV-stabilized PA6)
Corrosion Resistance	100% rust-proof plastic construction
Compliance	RoHS Compliant, REACH Compliant
Packaging
Standard Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag
Screws Included	Anchors sold separately, matching screw kits available
Certifications	ISO 9001:2015

Four Wing Knot Expansion Universal Wall Plugs Nylon Hollow Drywall Anchor For Light Picture Frame Mounting

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your plastic wall plugs?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this plastic wall plug be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling for soft substrates.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
