Expansion Plastic Drywall Anchor M6 M8 M10 M12 Four Side Plastic Wall Plugs Universal Uses

Name: Expansion Plastic Drywall Anchor M6 M8 M10 M12 Four Side Plastic Wall Plugs Universal Uses
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Universal Wall Plugs
Price: Negotiable USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Universal Wall Plugs

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Material:

Plastic

Diameter:

6MM; 8MM; 10MM

Finish:

Bright(Uncoated)

Color:

White, Gray, Blue, Oem

Name:

Plastic Four Side Anchor

Fastener Type:

Sleeve Anchors

Connection Method:

Bolt Joint

Application:

Hollow Wall,high Hole Brick,light Brick

Shear Strength:

5,000 Lb

Weight Capacity:

50 Lb

Measurement System:

Inch, Metric

Highlight:

expansion plastic drywall anchor

plastic drywall anchor m6

four side plastic wall plugs

Product Description

Expansion Plastic Drywall Anchor Wall M6 M8 M10 M12 Plastic Four Side Wall Plugs For Universal Uses

Product Description

Universal wall plugs are engineered for reliable fastening across all substrate types – solid, hollow, and panel materials. Featuring an advanced 4-way expansion mechanism, these plugs expand in four directions simultaneously, delivering superior grip and even load distribution in any building material.

The design ensures optimum force transmission into the substrate, guaranteeing high pull-out and shear resistance regardless of whether the base is concrete, brick, drywall, or hollow block.

Available in a full range of sizes (5mm to 14mm diameter), universal wall plugs are the go-to solution for construction professionals, contractors, and DIY users. Color-coded for instant size identification, they simplify inventory management and reduce installation errors.

Features

Engineered for universal use, these wall plugs perform reliably in any building material — solid, hollow, or panel. Whether you are fixing into concrete, solid brick, hollow block, drywall, or aerated concrete, one plug type covers all applications.

Unlike conventional expansion plugs that rely on a single-direction spread, this design features a precision-split body that expands simultaneously in four directions. This 4-way expansion ensures optimum force transmission into the substrate and guarantees high holding values in both solid materials (friction lock) and hollow materials (positive grip behind the surface).

The plug body is equipped with anti-rotation lugs that bite securely into the hole wall during installation. These lugs prevent the plug from spinning when the screw is being driven, enabling fast, one-handed tightening.

Available in a full size range from 5mm to 14mm diameter, each size is identified by a distinct color . This color-coded system allows for immediate recognition of the correct plug size on the job, minimizing installation errors, speeding up workflow, and simplifying warehouse stock management.

Recommended screw diameters range from M3 to M10, making these universal wall plugs suitable for a broad spectrum of loads — from lightweight picture frames to heavy radiators, wall cabinets, TV brackets, and sanitary fixtures. Their reliable performance has been verified across multiple substrates, providing proven dependability for both professional and DIY projects.

Technical Parameters

General Information
Product Name	Universal Wall Plugs
Material	Nylon (PA6) / Polyamide / Engineering Plastic
Color Options	Yellow, White, Gray, Blue, OEM
Head Type	Collar / Rimmed (prevents over-insertion)
Dimensions & Compatibility
Anchor Diameter (Ø)	5mm, 6mm, 8mm, 10mm, 12mm, 14mm
Anchor Length	25mm – 75mm (common: 25, 30, 35, 40, 50, 60, 70, 75mm)
Compatible Screw Diameter	M3 – M10 / #4 – #14 gauge (varies by plug size)
Pre-drill Hole Diameter	Matches plug diameter (5mm – 14mm)
Minimum Hole Depth	Plug length + 10mm (recommended)
Recommended Screw Length	Fixturing thickness + plug length + 1× screw diameter
4-Way Expansion Technology
Expansion Principle	Four-segment split design expands in four directions for maximum grip
Solid Substrate Behavior	4-way radial expansion creates secure friction lock in concrete and solid masonry
Hollow Substrate Behavior	Segments collapse and provide positive grip behind the wall surface
Key Features	• 4-way expansion form lock guarantees highest grip • Anti-rotation lugs prevent spinning in the hole • Collar prevents plug slipping into oversized holes • Expansion throughout the length of the plug
Load Capacity (Reference)
C20/25 Concrete	28kg (Ø5) – 628kg (Ø14) per anchor
Solid Brick	19kg (Ø5) – 224kg (Ø14) per anchor
Hollow Brick	13kg (Ø5) – 75kg (Ø14) per anchor
Plasterboard (12.5mm)	10kg (Ø5) – 6kg (Ø8) per anchor
Plasterboard (15mm)	24kg (Ø5) – 36kg (Ø8) per anchor
Installation
Installation Method	Pre-drill → clean hole → insert plug → drive screw → 4-way expansion
Installation Tool	Drill (masonry bit) + Screwdriver / Impact driver
Drilling Mode Note	For perforated building materials: use rotary mode (without hammer action)
Reusability	Limited – recommended to use new plug after removal
Application
Applicable Substrates	• Concrete (cracked and uncracked) • Solid brick / Solid sand-lime brick • Hollow brick / Vertically-perforated brick • Drywall / Plasterboard / Gypsum fibreboards • Aerated concrete (AAC) • Natural stone • Chipboard
Common Applications	• Shelving and cabinets • TV brackets and wall cabinets • Electrical fittings and cable trays • Lighting fixtures • Bathroom accessories and towel rails • Radiators and boilers • Suspended ceilings • Insulation board fixing
Environmental & Compliance
Temperature Range	-40°C to +85°C
Environmental Conditions	Weather-resistant, aging-resistant, corrosion-resistant
Compliance	RoHS Compliant, REACH Compliant
Certifications	ISO 9001 (manufacturing), ETA available for selected models

Expansion Plastic Drywall Anchor M6 M8 M10 M12 Four Side Plastic Wall Plugs Universal Uses

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
