Heavy Duty Self Tapping Wall Anchors For Handrail Grab Bar Mounting

Name: Heavy Duty Self Tapping Wall Anchors For Handrail Grab Bar Mounting
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Self Tapping Wall Anchors
Price: 0.02 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Self Tapping Wall Anchors
MOQ:	100 Pieces
Price:	USD 0.02-0.15 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	1000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Color:

White, Grey, OEM

Tip Type:

Sharp Conical

Finish:

Matte

Matching Screw:

Corrosion Proof:

100% Rust-Free

Material:

Nylon PA6

Base Type:

Disc Flange

Feature:

No Pre-Drilling

Use Case:

Handrails Safety

Thread Style:

Spiral Helical

Installation:

Self-Tapping Screw-In

Substrate:

Plasterboard

Head Shape:

Flat Disc

Anchor Diameter:

12mm

Anchor Length:

60mm

Safety Rating:

ADA Compliant

Impact Class:

Heavy Duty

Thread Depth:

2.5mm Profile

Packaging Details:

Inner poly bag or small box, export corrugated carton with custom marking available

Highlight:

heavy duty self tapping wall anchors

heavy duty self tapping drywall anchors

handrail grab self tapping wall anchors

Product Description

Heavy Duty Nylon Self-Tapping Plasterboard Anchor Spiral Wall Plug for Handrail and Grab Bar Safety Mounting

Product Description

The Heavy Duty Nylon Self-Tapping Plasterboard Anchor is a rugged plastic fastening solution engineered for safety-critical handrail, grab bar, and accessibility fixture installations on plasterboard and double-layer drywall surfaces. The anchor features an impact-resistant PA6 nylon core that withstands sudden dynamic loads typical of handrail and grab bar usage, along with natural vibration-dampening properties that prevent anchor loosening over years of service on plasterboard walls. The deep spiral thread design maximizes surface contact within the gypsum board structure, creating a dependable mechanical lock that resists pull-out forces in both single and double-layer plasterboard installations. A flat disc base provides a flush bearing surface for clean, professional-looking installations. To install on plasterboard, mark the mounting position, position the conical tip, and drive clockwise with an impact driver until the disc base sits flush and firm resistance confirms proper seating.

Features

Impact-Absorbing Nylon Core - The specially formulated impact-resistant PA6 compound absorbs sudden shock loads from handrail grab events on plasterboard walls without cracking, maintaining anchor integrity in safety-critical applications where failure is not an option.

Seismic-Grade Vibration Control - The nylon body naturally dampens building vibrations transmitted through plasterboard walls from foot traffic and door slamming, preventing gradual anchor loosening that compromises safety grab bar reliability over time.

Progressive Thread Locking - Thread pitch gradually tightens toward the anchor head, concentrating grip density near the plasterboard surface where pull-out forces peak — a critical feature for handrail installations subject to repeated loading on gypsum walls.

Double-Layer Drywall Penetration - The 60mm length and 12mm diameter with deep spiral threads achieve strong mechanical interlock through single and double-layer plasterboard, delivering up to 42kg load capacity for safe handrail and grab bar anchoring.

Technical Parameters

General Information
Product Name	Nylon Spiral Self Tapping Wall Anchor ST Series
Model Number	ST-12060
Anchor Diameter	12mm
Anchor Length	60mm
Material	Nylon PA6 / Polyamide Engineering Plastic
Color Options	White, Grey, Natural (customizable)
Anchor Structure	Spiral helical body with conical drill tip and disc base
Dimensions & Compatibility
Matching Screw Size	M8 (self-tapping screw)
Self-Drilling Tip	Sharp conical pointed tip
Base Type	Wide disc flange for wall surface support
Thread Type	Deep spiral / helical cutting thread
Pre-drill Required	No for drywall/plasterboard; optional for concrete/brick
Recommended Drill Size	12mm or 11mm for hard substrates
Load Capacity
Load Capacity (Plasterboard)	Up to 42kg per anchor
Pull-Out Resistance	Varies by plasterboard thickness and anchor size
Shear Strength	Up to 68kg in 12.5mm plasterboard
Installation
Installation Method	Self-tapping — screw directly into plasterboard surface
Installation Tool	Screwdriver / Impact driver with Phillips bit
Installation Steps	Mark position → place tip on plasterboard → drive clockwise until flush → insert screw
Key Benefit	No pre-drilling required for plasterboard and gypsum board surfaces
Anti-Rotation Feature	Integrated anti-spin ribs prevent rotation during installation
Application
Suitable Substrates	Plasterboard, Drywall, Gypsum Board (also compatible with Hollow Brick, Cavity Wall, Aerated Concrete, Lightweight Concrete)
Common Uses	Handrail and Safety Grab Bar Mounting on Plasterboard
Environmental & Compliance
Temperature Range	-40°C to +80°C
Environmental Suitability	Indoor and outdoor use (UV-stabilized PA6)
Corrosion Resistance	100% rust-proof plastic construction
Compliance	RoHS Compliant, REACH Compliant
Packaging
Standard Packaging	100 / 200 / 500 / 1000 pieces per box or poly bag
Screws Included	Anchors sold separately, screw kits available
Certifications	ISO 9001:2015

Heavy Duty Self Tapping Wall Anchors For Handrail Grab Bar Mounting

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your plastic spiral anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this plastic spiral anchor be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
