Pre Assembled Furring Channel Leveling Anchor Plastic Quick Install

Name: Pre Assembled Furring Channel Leveling Anchor Plastic Quick Install
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Furring Channel Leveling Anchor
Price: 0.07 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Furring Channel Leveling Anchor
MOQ:	1000 Pieces
Price:	USD 0.07 - 0.40 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	600000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Material:

Nylon PA6 Body + Pre-Inserted Zinc-Plated Steel Screw

Available Sizes:

M6, M8, M10

Assembly Type:

Pre-assembled Anchor With Screw Partially Inserted (ready To Use)

Anchor Type:

Pre-Assembled Furring Channel Leveling Anchor

Head Design:

Square Head Phillips Drive

Installation Speed:

50% Faster Than Separate Anchor+screw Assembly

Installation Method:

Drill, Clean Dust, Vertical Hammer-in, Diagonal Tighten

Application:

High-Volume Ceiling Framing, Rapid Suspension System Installation

Packaging Details:

WNRLN branded inner box, export-grade corrugated carton

Highlight:

furring channel leveling anchor plastic

pre assembled furring channel leveling anchor

Plastic Furring Channel Leveling Anchor

Product Description

Pre Assembled Plastic Furring Channel Leveling Anchor Quick Install Nylon Expansion Bolt for Fast Ceiling Suspension

Product Description

The Pre-Assembled Plastic Furring Channel Leveling Anchor is engineered for high-volume ceiling suspension and furring channel framing projects where installation speed directly impacts project cost and schedule. Each anchor arrives with the screw pre-inserted into the nylon PA6 body in the correct alignment, eliminating the separate step of positioning and starting the screw during overhead installation. The installer simply drills the matching hole, cleans the dust, vertically hammers the complete assembly flush into the substrate, and diagonally tightens the pre-inserted screw to engage the split-body expansion mechanism. This pre-assembled configuration reduces per-anchor installation time by approximately 50% compared to separate anchor-and-screw assemblies, translating to significant labor cost savings on large-scale commercial ceiling projects. The square head design ensures reliable torque transfer without cam-out during the diagonal tightening phase even at overhead working angles.

Features

Ready-to-Use Pre-Assembled Format: Screw is pre-inserted into the nylon PA6 anchor body in factory alignment — just pick up, drill hole, clean dust, hammer in, and diagonally tighten with no separate screw positioning step.

50% Installation Time Reduction: Eliminate the overhead screw alignment and starting step for each anchor, cutting total per-point installation time significantly on large commercial ceiling projects.

Consistent Factory Assembly Quality: Pre-insertion at the correct depth and alignment ensures the screw engages the expansion mechanism optimally on every anchor, eliminating on-site assembly errors.

Standard Square Head Compatibility: Pre-inserted screw maintains the same square head Phillips drive interface, compatible with standard impact drivers and torque wrenches used by ceiling installation crews.

Technical Parameters

General Information
Product Name	Pre-Assembled Plastic Furring Channel Leveling Anchor
Material	Nylon PA6 + Pre-Inserted Zinc-Plated Steel Screw
Assembly Type	Factory pre-assembled: screw partially inserted, ready for immediate installation
Head Design	Square head Phillips drive (pre-inserted)
Installation
Installation Method	Drill matching hole → clean dust → vertical hammer-in complete assembly → diagonal tighten
Installation Tool	Electric hammer drill + Impact driver (Phillips square bit)
Time per Anchor	Approximately 15-20 seconds (50% faster)
Key Feature	Pre-assembled format eliminates separate screw positioning step for rapid high-volume installation
Performance & Load Capacity
Tensile Load (M8 in C20/25)	120 kg
Tensile Load (M10 in C20/25)	180 kg
Temperature Range	-20°C to +80°C
Environmental Compliance	RoHS Compliant, REACH Compliant
Standards Compliance	ISO 9001:2015
Application
Applicable Substrates	Concrete, solid brick, aerated concrete block
Common Applications	High-volume commercial ceiling framing, rapid suspension system installation, large-scale drywall grid projects
Usage Restriction	Verify full expansion engagement after tightening; not for overhead dynamic loads
Packaging & Compliance
Standard Packaging	Pre-assembled anchor sets in compartment trays
Packaging Quantity	200 sets per box, export carton
Certifications	ISO 9001:2015

Pre Assembled Furring Channel Leveling Anchor Plastic Quick Install

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
