Weatherproof Zinc Nylon Hammer Plastic Expansion Anchors Plugs For Exterior Use

Name: Weatherproof Zinc Nylon Hammer Plastic Expansion Anchors Plugs For Exterior Use
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Anchors
Price: 0.02 USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Anchors
MOQ:	1000 Pieces
Price:	USD 0.02 - 0.08 / Piece
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	3000000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Product Name:

Nylon Sleeve Hammer-Set Plastic Expansion Anchor With Zinc-Plated Nail For Exterior Use

Material:

Weather-Resistant Nylon PA6 Sleeve + Hot-Dip Zinc-Plated Steel Nail

Anchor Type:

Hammer-Set Sleeve Expansion Anchor With Round Head, Exterior Grade

Suitable Substrate:

Concrete, Brick, Masonry For Exterior Exposure

Diameter:

8 Mm, 10 Mm, 12 Mm

Length:

40 Mm - 100 Mm

Corrosion Protection:

Hot-Dip Zinc-Plated Nail For Superior Rust Resistance

Application:

Outdoor Fence, Gate, Facade Fixture, Exterior Light, Rainwater Pipe Bracket

Packaging Details:

1000 pcs/bag, export carton

Highlight:

nylon hammer plastic expansion anchors

weatherproof plastic expansion anchors

weatherproof expanding plastic screw anchors

Product Description

Nylon Sleeve Hammer Set Plastic Expansion Anchor Round Head Nail Fixing Plugs Zinc Nail for Exterior Application

Product Description

The Zinc Nail Nylon Sleeve Hammer-Set Plastic Expansion Anchor is upgraded with a hot-dip zinc-plated steel nail for superior corrosion resistance, making it the recommended choice for exterior and outdoor anchoring applications where exposure to rain, humidity, and temperature fluctuations can cause standard steel nails to rust and stain surrounding surfaces. The weather-resistant nylon PA6 sleeve combined with the zinc-plated nail provides a complete corrosion-resistant anchoring system for exterior wall fixtures.

Designed for outdoor fence bracket mounting, gate hinge anchoring, facade fixture installation, exterior light fixing, rainwater downpipe bracket attachment, and any application where the anchor will be exposed to outdoor weather conditions. Available in 8 mm, 10 mm, and 12 mm diameters with lengths from 40 mm to 100 mm, it provides reliable exterior anchoring with long-term corrosion protection. Manufactured to ISO 9001:2015 standards with additional quality checks on zinc plating thickness and adhesion.

Features

Hot-dip zinc-plated steel nail provides superior corrosion and rust resistance compared to standard electroplated nails. Prevents rust staining on exterior wall surfaces, maintaining clean appearance over the service life. Suitable for outdoor exposure to rain, humidity, coastal air, and temperature cycling.

Weather-resistant nylon PA6 sleeve material maintains mechanical properties in outdoor environments. UV-stabilized compound resists degradation from sunlight exposure in protected positions. Complete corrosion-resistant system with no exposed unprotected metal.

Available in standard 8 mm, 10 mm, and 12 mm diameters with 40 mm to 100 mm lengths. Same reliable hammer-in installation and expansion grip performance as our interior-grade anchors. Compatible with standard self-tapping screws and fixture hardware.

Simple hammer-in installation – pre-drill hole, insert anchor, hammer zinc nail to expand. The zinc-plated nail drives smoothly through the nylon sleeve without flaking or binding. Provides reliable pull-out resistance in concrete, brick, and masonry substrates.

Ideal for outdoor fence bracket and gate hinge anchoring, facade fixture installation, exterior light fixing, rainwater pipe brackets, and external signage mounting. The recommended exterior-grade anchor for all outdoor construction and renovation projects.

Technical Parameters

General Information
Product Name	Zinc Nail Nylon Sleeve Hammer-Set Plastic Expansion Anchor for Exterior Use
Material	Weather-Resistant Nylon PA6 Sleeve + Hot-Dip Zinc-Plated Steel Nail
Anchor Type	Hammer-Set Sleeve Expansion Anchor with Round Head, Exterior Grade
Head Type	Round Countersunk Head
Substrate	Concrete, Brick, Masonry for Exterior Exposure
Dimensions
Anchor Diameter (∅)	8 mm, 10 mm, 12 mm
Anchor Length	40 mm – 100 mm
Screw Compatibility	M4 / M5 / M6 (stainless steel or zinc-plated self-tapping screws recommended)
Pre-drilled Hole Diameter	0.5–1 mm larger than anchor OD
Effective Anchoring Depth	≥ 25 mm into masonry substrate
Installation
Installation Method	Hammer-in – pre-drill, insert anchor, hammer zinc nail to expand, fixture secured with corrosion-resistant screws
Working Principle	Nail drives through sleeve, expanding ribs grip borehole wall, zinc coating prevents rust
Temperature Range	-40°C to +80°C
Matching & Application
Recommended Fixtures	Outdoor fences, gates, facade panels, exterior lights, rainwater pipe brackets, signage
Applications	Outdoor fence, gate hinge, facade fixture, exterior light, rainwater pipe bracket, external signage
Usage Scope	Exterior and outdoor anchoring (all weather conditions)

Weatherproof Zinc Nylon Hammer Plastic Expansion Anchors Plugs For Exterior Use

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
