Plastic Expansion Screws Self Tapping Furring Channel Leveling Anchor Heavy Duty Nylon

Name: Plastic Expansion Screws Self Tapping Furring Channel Leveling Anchor Heavy Duty Nylon
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Furring Channel Leveling Anchor
Price: Negotiable USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Furring Channel Leveling Anchor

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Compatible Material:

Furring Channel

Type:

Plastic Expansion Anchors

Material:

Plastic

Application:

Furring Channel

Head Type:

Flat，rectangle

Thread Size:

Customized

Surface Treatment:

Plain

Fastener Type:

Drop In Anchors

Function:

Furring Channel Leveling

Finish:

Bright(Uncoated)

Highlight:

self tapping furring channel leveling anchor

furring channel leveling anchor heavy duty

Plastic Furring Channel Leveling Anchor

Product Description

Plastic Expansion Screws Self Tapping Anchors Heavy Duty Nylon Furring Channel Leveling Anchors

Product Description

The product is a fastening component specifically designed for the installation and leveling of light steel keel in building decoration engineering. It combines the anchoring function of traditional expansion pipes with the adjustment advantages of specialized leveling structures, aiming to solve the problems of difficult control of keel flatness, low installation efficiency, and easy deformation in ceiling or partition construction.

As a basic anchor, it is implanted into prefabricated holes in walls or floors. When the screw is tightened, the expansion tube expands and tightly engages with the base surface, providing stable tensile support. Common materials include high-strength nylon or plastic, and some high-end products adopt fish scale pattern design to enhance multi-directional cushioning and grip.

Its structural feature is that there is a fixed isolation plate (or limit plate) between the threaded tip and the nut. After the screw is screwed into the expansion tube, the isolation plate can directly press against the back of the keel, and the height position of the keel can be precisely adjusted by rotating the nut, achieving the combination of "rigid support" and "flexible adjustment".

Features

Advanced Ribbed Body and Split Expansion Design Provides Superior Pull Out Resistance Prevents Rotation and Ensures Secure Fixation in Both Solid and Cavity Substrates

Available in Standard Sizes M5 M6 M8 M10 and M12 with Complete Kit Including Zinc Plated Carbon Steel Phillips Pan Head or Countersunk Flat Head Screws

Suitable for Fastening Heavy Objects Such as Steel Brackets Cable Trays Electrical Conduits Ceiling Fans Window Frames and Sanitary Fixtures to Masonry Surfaces

Simple One Step Installation with Hammer Drill and Screwdriver Reduces Labor Costs Eliminates Extra Tooling and Saves Installation Time by Up to 50 Percent

Multiple Expansion Depth Options and Universal Type Design Compatible with Most Standard Drill Bits and Screw Sizes for Versatile Project Use

Bulk Packaging Solutions in Poly Bags Plastic Boxes and Export Cartons with Custom Branding Labeling and Color Coding Available for Distributor Requirements

Technical Parameters

General Information
Product Name	Furring Channel Leveling Anchor
Material	Nylon (PA6) / Engineering Plastic / Galvanized Steel
Color Options	Natural, White (customizable)
Product Type	Direct fixing anchor for furring channel leveling
Dimensions & Compatibility
Anchor Diameter	7.5mm – 9.0mm (typical)
Anchor Length	30mm – 80mm (varies by substrate and channel type)
Thread Size Compatibility	M6 (typical), M8 / M10 (heavy-duty models)
Pre-drill Hole Diameter	8mm – 10mm (depending on anchor size)
Performance & Load Capacity
Typical Load Capacity	Varies by substrate and anchor size
Temperature Range	-40°C to +80°C
Environmental Compliance	RoHS Compliant, REACH Compliant
Application
Applicable Substrates	• Concrete (reinforced and unreinforced) • Solid masonry units • Hollow concrete block
Common Applications	• Direct fixing of furring channels to walls • Wall leveling and straightening • Drywall framing support • Cladding and facade systems
Packaging
Standard Packaging	50 pieces per box (typical)
Packaging Quantity	50 sets / 100 sets / 200 sets per carton (varies by model)
Certifications	ISO 9001 (manufacturing), ETA (optional)

Plastic Expansion Screws Self Tapping Furring Channel Leveling Anchor Heavy Duty Nylon

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
