Dilatant Steel Head Self Drilling Drywall Expansion Anchor Bolt Pole Anchor

Name: Dilatant Steel Head Self Drilling Drywall Expansion Anchor Bolt Pole Anchor
Brand: Hebei Cangrui Plastic Products Co., Ltd
SKU: Plastic Expansion Anchors
Price: Negotiable USD
Availability: InStock

Brand Name:	CangRui
Model Number:	Plastic Expansion Anchors

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Fastener Type:

Self Drilling Drywall Anchors

Raw Material:

Nylon PP PE/Steel

Application:

Building Construction Material Fixing

Connection Method:

Bolt Joint

Compatible Material:

Solid Concrete, Brick Wall, Masonry, Hollow Block

Diameter:

6mm, 8mm, 10mm, 12mm

Material:

PE Plastic + Carbon Steel / 304 Stainless Steel

Weight Capacity:

0.6KN~4.2KN

Type:

Wedge Anchors

Capacity:

Strong

Size Length:

25~60mm

Highlight:

drywall expansion anchor bolt

dilatant expansion anchor bolt

dilatant expansion bolt sleeve anchor

Product Description

Dilatant Steel Head Self Drilling Drywall Expansion Anchor Bolt Pole Anchor

Product Description

As a fixed wall anchor, the Plastic Expansion Anchor is made of high-quality polypropylene material that ensures long-lasting durability and strength. This material also makes it lightweight and easy to install. With its excellent load capacity, this expansion anchor can handle different weights depending on its size and installation method.

The Polypropylene Expansion Anchor is a type of wall plug plastic anchor that is widely used in the construction industry. This anchor is designed to expand once inserted into a pre-drilled hole, creating a secure hold in a variety of materials such as concrete, brick, and masonry. The expansion mechanism of this anchor ensures a tight grip, making it suitable for a wide range of applications, from hanging shelves and mirrors to securing electrical boxes and plumbing fixtures.

Features

1. Designed for quick and easy hammer-in installation. No special tools required – simply insert into the pre-drilled hole and tap firmly with a hammer. Ideal for high-volume projects, reducing labor time and installation costs.

2. Manufactured from premium engineering plastic, offering excellent impact resistance, aging resistance, and corrosion resistance. Performs reliably in temperatures ranging from -40°C to +80°C, suitable for both indoor and outdoor applications.

3. Available in diameters from 6mm to 14mm and lengths from 26mm to 200mm, compatible with M3 to M10 self-tapping screws. Suitable for concrete, solid brick, hollow brick, block, and plasterboard – one product line covers multiple substrates.

4. Features multiple longitudinal ribs and anti-slip barbs on the outer wall. When driven in, the ribs expand against the hole wall, creating a strong friction lock. Provides high pull-out resistance in solid materials and reliable anchoring in hollow substrates.

5. Offers excellent value with broad application potential. Widely used in building renovation, insulation board fixing, pipe support installation, decorative hanging, and more. A reliable fixing solution for construction and decoration projects.

Technical Parameters

General Information
Product Name	Hammer-in Expansion Anchor
Material	Nylon (PA6) / Polyamide / Engineering Plastic
Color	Natural Nylon / White / Custom
Substrate	Concrete, Solid Brick, Hollow Brick, Block, Plasterboard
Dimensions
Anchor Diameter (∅)	6mm, 8mm, 10mm, 12mm, 14mm (standard sizes)
Anchor Length	26mm – 200mm
Screw Diameter Compatibility	M3 / M4 / M5 / M6 / M8 / M10 (self-tapping screws)
Pre-drilled Hole Diameter	0.5–1mm larger than anchor OD (see installation guide)
Effective Anchoring Depth	≥ 20mm (varies by substrate)
Installation
Installation Method	Hammer-in / Knock-in – drive directly into pre-drilled hole with a hammer
Working Principle	Ribs expand against hole wall upon driving, creating friction lock
Temperature Range	-40°C to +80°C
Matching & Application
Recommended Screws	Hardened self-tapping screws (countersunk / pan / large flange)
Applications	Decorative hanging, pipe support fixing, insulation board fixing, lightweight fixture installation
Usage Scope	Indoor & outdoor general use (not for heavy-duty / overhead loads)

Dilatant Steel Head Self Drilling Drywall Expansion Anchor Bolt Pole Anchor

FAQ

Do you have full standard sizes in stock for plastic expansion anchors?

We have complete conventional sizes in stock, full specifications ready for immediate shipment, support mixed size bulk wholesale.

What is the material and load-bearing capacity of your Plastic insulation anchors?

Made of high-quality new engineering plastic, high toughness anti-crack; stable holding force for drywall, hollow wall and plasterboard, suitable for light and medium load installation.

What types of walls and base materials can this Plastic insulation anchors be used for?

It is widely applicable to gypsum board, plasterboard, hollow brick, aerated concrete, light concrete and cavity wall, no need pre-drilling.

What is your MOQ and wholesale price discount policy?

Low MOQ supports small batch trial order; the more quantity you order, the more favorable wholesale price, exclusive discount for long-term distributors.

What is your production lead time and mass supply capacity?

Spot goods can be shipped within 3-7 days; large batch orders 7-15 days, stable daily output to support continuous large-volume supply for distributors.

Can you customize size, color, packaging and OEM private label?

We support custom size, color, box packaging, carton marking and OEM/ODM private label service for your local market sales.

Do you support mixed batch with other fastener products?

Yes, you can mix order with our other fasteners like screws, bolts and wall plugs to fill one container conveniently.

Can I get free samples for quality checking?

Free samples are available, customers only need to bear the freight; sample size and quantity can be arranged according to your requirement.
